Fire retardant coating for cable eco-friendly
2.Performance: High durability, long service life, excellent flame retardancy, anti-aging, anti-corrosion, strong adhesion;
3.Application: Critical cables in power stations, high-rises, industrial plants and long-term use scenarios;
4.Construction: Spraying, fast drying, strong film toughness, no frequent reapplication, low maintenance cost;
5.Parameter: Fire resistance ≥2h, service life ≥12 years, flame-retardant grade A, temperature resistance up to 1150℃.
6. +5~40°C; RH≤85%; substrate ≥3°C above dew point.
7. Indoor lacks UV/weather resistance; outdoor requires UV/weather topcoat.
8. Indoor use; outdoor >5y needs UV/weather-resistant finish.
9. Store 5–45°C dry; shelf life water/solvent 12m, cement 6m.
10. Water/cement non-hazardous; solvent (>60°C) flammable UN1263 Class 3.
11. VOC: water≤120g/L; solvent≤650g/L compliant.
- Product Description
Fire Retardant Coating for Cable: Eco-Friendly Protection for Critical Infrastructure
Extraordinary safety measures are needed to keep important wire systems safe in power plants, high-rise buildings, and factories. Our Fire retardant coating for cable eco-friendly provides business-level performance with a fire resistance time of at least 90 minutes, an FV-0 flame retardant grade, and temperature resistance up to 1150℃. This covering has been tested to last more than 12 years and has a flame spread ratio of -25. It protects against fire risks for a long time while still being very good at insulating and having no effect on how well the cables conduct electricity.
Why Choose Our Eco-Friendly Cable Fire Protection Solution?
You should have wire security that doesn't skimp on safety or durability. When our coating comes into contact with fire, it quickly grows and forms a thick layer of carbonised insulation that stops the flame from spreading and stops dangerous wire short circuits.
Safety meets caring for the earth. This water-based mixture has a mild smell and doesn't have any dangerous volatile substances in it. You get solid safety for your workers that meets the standards of the ISO 14001 Environmental Management System.
With 30 years of experience in coatings, we've improved our recipe to give you better adhesion, anti-aging, and corrosion protection. Your wires are safe even in tough places, like cable trenches and steep shafts.
Technical Parameters
| Parameter | Specification |
|---|---|
| Appearance | Black/grey viscous liquid, uniform with no sediment |
| Flame Retardant Grade | FV-0 grade |
| Fire Resistance Time | ≥90 minutes |
| Flame Spread Ratio | ≤25 |
| Temperature Resistance | Up to 1150℃ |
| Service Life | ≥12 years |
| Flexibility | ≤1 mm, no cracks |
| Oil Resistance | No corrosion or flaking after 36 hours |
| Corrosion Resistance | Resistant to acids, alkalis and salt spray |
| Coating Thickness | 0.5–1 mm |
| Construction Temperature | 0–40°C (optimal: 5–40°C, RH≤85%) |
| Drying Method | Air-dry at room temperature |
| Surface Dry Time | 1–2 hours |
| Full Cure Time | 24 hours |
| Coverage Rate | 0.5–0.8 kg per square meter |
| Insulation Property | Excellent; non-conductive |
| VOC Content | Water-based ≤120g/L |
| Storage Condition | 5–45°C, dry location; shelf life 12 months |
| Applicable Scenes | Power cables, telecommunications cables, cable trays |
Key Applications for Your Projects
Power Infrastructure: Cable shafts in substations and power plants require maximum protection. Our fire retardant coating for cable eco-friendly formula meets these demanding requirements.
Commercial Buildings: Cable systems that don't break down are important for shopping malls, hotels, hospitals, and office buildings. It gives you peace of mind to know that your fire safety will work.
Transportation Networks: Both subway tubes and machine rooms have their own problems. This coating is resistant to water and lasts a long time in tough underground circumstances.
Industrial Facilities: Places that make things need wire security that can handle being around chemicals, oils, and changes in temperature. Our covering does a great job in every way.
Simple Application Process
You'll appreciate how straightforward installation is. Apply by brushing, rolling, or spraying—just like regular paint.
Quick drying saves you time. Surface dry occurs in 1–2 hours, with intervals between coats of just 4 hours. Most projects need 2–3 coats to achieve optimal thickness.
Work in comfortable conditions. Apply between 5°C and 35°C. Avoid rainy or humid conditions for best results.
Indoor applications work perfectly as-is. For outdoor installations exceeding 5 years, you'll want to add a UV and weather-resistant topcoat for extended protection.
What Makes Our Solution Different?
Enterprise-level durability: other coatings need to be reapplied often, but ours stays protective for more than 12 years. You cut down on upkeep costs by a lot.
No loss of safety: the non-conductive formula keeps the electrical features of your wire. Your systems work normally while getting important fire safety.
Full proof: We give test results and conformity papers that meet fire safety standards for checks. It's easy for your projects to pass safety checks.
Follow global standards: With CE Certification, ISO 9001, ISO 14001, and ISO 45001, you can work on projects with people from the Middle East and Southeast Asia.
Comprehensive Support Throughout Your Project
Our technical experts help you choose the right product for your wire types and fire safety needs before you place your order. We give you free samples to test how well they work.
You get full installation manuals and 24/7 remote help while the building is being built. For complicated problems, our senior experts can make answers just for you.
Once the job is done, we help with the acceptance paperwork and setting up the fire safety check. You get free remote expert help for life and better prices on future jobs.
FAQ
Q: What exactly does this coating do for cables?
A: The coating rapidly expands to produce a thermal barrier during fire. This avoids cable fires and flames along cable lines. Your emergency lighting and power systems work when needed.
Q: What fire safety requirements does it meet?
A: The cable coating meets GB 28374-2012 "Fire-Retardant Coating for Cables." Official test reports meet fire safety checks and regulations.
Q: Are water-based versions eco-friendly?
A: Absolutely. The standard water-based recipe is non-toxic, low-odor, and non-flammable. It satisfies high environmental regulations and is safe for application personnel. Avoid risks of solvent-based alternatives.
Q: Will this coating affect my cable's electrical properties?
A: Absolutely not. Drying makes the film non-conductive and very insulating. Your wires stay electrically efficient while providing fire safety.
Q: Can I apply this coating outdoors?
A: The coating is for cable trenches, trays, and vertical shafts indoors. To ensure long-term functioning, use fire-resistant wrapping and cable trays for outdoor cables.
Partner With Proven Expertise
Since 2019, Henan Banggu Fire Technology has built on over 30 years of coating manufacturing excellence. Located in China's "Capital of Anti-Corrosion," we combine traditional expertise with modern innovation.
You benefit from our integrated capabilities—from R&D through production to global logistics. We hold land and sea transportation permits, ensuring reliable delivery to your project site.
Our product solutions help contractors, distributors, and project owners worldwide achieve compliant, cost-effective protection. You get quality that wins projects and builds lasting partnerships.
Contact Us
Ready to Protect Your Cable Infrastructure with Fire retardant coating for cable eco-friendly? Let's discuss your specific requirements. Contact us at banggu@bgfireproof.com for technical consultation, samples, or project quotes today.
